Single Girder Bridge Crane / EOT Crane Remote Control With Electric Hoist
LDA Single Girder EOT Bridge Crane
The single beam crane is small lifting capacity and travel along high I-Steel track.
(1) Single girder overhead crane is also called single beam bridge crane, It is consists of the main girder, end girder, electric hoist.
(2) LDA electric single girder overhead crane is improved and
designed on the basis of LD model. It is characterized by more
reasonable structure and higher strength steel as a whole. Used
together with CD1, MD1 model electric hoist as a complete set.
which is the most popular use crane machinery on the market at
present.
(3) LDA electric single girder overhead crane can be widely used in
plants, warehouses, material stocks to lift goods. It is prohibited
to use the equipment in the combustible, explosive to corrosives
environment.
Single Girder Overhead Crane Drawing
| Lifting capacity (T) | 1, 2, 3, 5, 10T | 16, 20T | |||||||||||
| Span(M) | 7.5-22.5M | ||||||||||||
| Crane traveling mechanism | Traveling speed(m/min) | 20 | 30 | 45 | 60 | 75 | 20 | ||||||
| Reducer ratio | 58.78 | 39.38 | 26.36 | 19.37 | 15.88 | 58.78 | |||||||
| Motor | Model | ZDY21-4 | ZDY21-4 | ZDY122-4 | |||||||||
| Power(kw) | 2× 0.8 | 2× 1.5 | 1.5× 2 | ||||||||||
| Rotation (m/min) | 1380 | 1380 | |||||||||||
| Lifting mechanism (electric hoist)& electric hoist traveling mechanism | Electric hoist model | CD1/MD1 | MD1/HC | ||||||||||
| Lifting speed (m/min) | 8, 8/0.8 7, 7/0.7 | 3.5 3.5/0.35 | |||||||||||
| Lifting height (m) | 6, 9, 12, 18, 24, 30 | 12, 18, 24, 30 | |||||||||||
| Traveling speed (m/min) | 20(30) | 20(30) | |||||||||||
| Motor | Taper Squirrel-cage type | Taper Squirrel-cage type | |||||||||||
| Work duty | A3-A5 | ||||||||||||
| Power supply | 380V 50HZ three phase | ||||||||||||
| Wheel diameter | 270mm | 370mm | |||||||||||
| Width of trail | 37-70mm | 37-70mm | |||||||||||
|
|
